• AC regulator rectifier
  • Direct replacement to your original unit.
  • Plug-and-play, direct fit, easy installation.
  • No assembly required
  • The Quality exceeds the OEM equipment
  • Higher grade of electric components.
  • All products shipped are tested

Please note that there are TWO possible regulators for the KingQuad LTA 700X 2006. Make sure you have the production number that matches your vehicle. All item pictures are accurate, if in doubt, do not hesitate and compare our item to your original part.

Production Number :
F.NO.5SAAP41A 67110000 (OEM# 32800-41F10 & 32800-47H00) : RM30502
F.NO.5SAAP41A 67110001~ (OEM# 32800-42F00) : RM30806

Dimensions :
Width : 93 mm
Length : 27 mm
Height : 102 mm
Fixation holes center to center : 72 mm

Other specifications :
Number of plugs : 1
Number of pins : 6


Before installing your new regulator/rectifier:
Check the AC output of the stator
Replace any burned or corroded connectors on stator and regulator/rectifier
Check and repair any melted wiring
Use hi-temp dielectric grease on all connectors

(RMS30806_19)

SKU RMS30806_19
Barcode # 9420060000000
Brand RMStator
Unit Of Measure ea
