RMSTATOR is specialized in designing and manufacturing innovative electrical and electronic components for Powersports vehicles like motorcycles, ATV, SxS, UTV, snowmobiles, and PWC. Through unrelenting quality control, we ensure that each component meets or exceeds the OEM specs. With over 25 product families, rest assured that you will find the part you need.

• Direct replacement to your original unit
• Plug-and-play, direct fit, easy installation
• Highest grade of lamination materials
• Highest grade of copper winding, resistant to 200 degrees Celsius
• Connector included

Battery condition is extremely important. No stator can work correctly with a bad or weak battery. Always fully charge your battery before performing any charging system tests or replacing parts. If there is any doubt, have the battery load tested or replaced.

Please Note There are two possible stators for most of the Outlander models from 2016 through 2019; please check the specifications below against your existing stator to ensure you are ordering correctly

Dimensions:
Interior diameter: 41 mm
Exterior diameter: 104 mm
Thickness: 30 mm Length of wires stator to grommet : 140 mm
Length of wires grommet to plug : 850 mm

Other specifications:
Number of wires: 3
Number of plugs: 1
Number of terminals: 3

Wire to wire resistance:
Alternator: Yellow between each Yellow = 0.4 ohms +/-20%
